1.25Gbps SFP Optical Transceiver, 10km
Features
· Data-rate of 1.25Gbps operation
· 1310nm DFB laser and PIN photodetector for 10km transmission
· Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
· Digital Diagnostic Monitoring:
· Internal Calibration or External Calibration
· Compatible with SONET OC-24-LR-1
· Compatible with RoHS
· +3.3V single power supply
· Operating case temperature:
· Standard : 0 to +70°C
· Extended : -20 to +85°C
· Industrial : -40 to +85°C
Applications
· Gigabit Ethernet
· Fiber Channel
· Switch to Switch interface
· Switched backplane applications
· Router/Server interface
· Other optical transmission systems
Description
The SFP transceivers are high performance, cost effective modules supporting data-rate of 1.25Gbps and 10km transmission distance with SMF.
The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
Ordering information
Part Number | Product Description |
HG | 1310nm, 1.25Gbps, 10km, 0ºC ~ +70ºC |
HG | 1310nm, 1.25Gbps, 10km, 0ºC ~ +70ºC, With Digital Diagnostic Monitoring |
HG | 1310nm, 1.25Gbps, 10km, -20ºC ~ +85ºC |
HG | 1310nm, 1.25Gbps, 10km, -20ºC ~ +85ºC, With Digital Diagnostic Monitoring |
HG | 1310nm, 1.25Gbps, 10km, -40ºC ~ +85ºC |
HG | 1310nm, 1.25Gbps, 10km, -40ºC ~ +85ºC, With Digital Diagnostic Monitoring |
